ClickTight Car Seats: Hip Adjustment for Extra Room

Our ClickTight convertible car seats include an innovative harness system that allows you to adjust the harness positioning in two places – at the child’s hip and shoulder levels – to provide a custom fit for your child. If your child needs more room to fit comfortably within the harness.

IMPORTANT: Adjust the harness to the shortened length if a snug harness cannot be achieved with a small infant (approx. 10 lbs. and under).

Open the ClickTight Panel

1. Identify the ClickTight Key. Find the indention.

ClickTight Key Step 1

2. Place your finger on the indention and push forward.

ClickTight Step 2

3. Hold the ClickTight Key with both fingers and rotate clockwise to unlock.

ClickTight Step 3

4. Lift the front panel of the seat to reveal the belt path.

ClickTight Step 4

Any doubts? Watch our video below.

Step 2: Adjust the Harness to the Long Length

The long harness length should ONLY be used for children aged 2 and over if extra room is needed. For children under 2 years old, the harness MUST be the short length.

1. Disconnect the end of one harness strap from the anchor on the bottom side of the seating area.

Adjusting the Harness - Step 1

2. Unwrap the end of the harness strap from the metal bar and pull to the top of the seating area.

Adjusting the Harness Step 2

3. Hook the harness loop to the same anchor from the top of the seating area ensuring that it is secure inside the hook.

Adjusting the Harness Step 3

4. Repeat on the other side.

Adjusting the Harness Step 4

IMPORTANT: Prior to using the seat, ensure that the harness straps are securely connected to the anchors inside the hook.
